GRAVOGRAPH LS900 XP - Air Extraction System Installation (Optional)

30
M_LS900 XP IQ Energy_EN_B
Recommendations for installation
3. Air extraction system (optional)
Never operate the machine without a fume and gas extraction system that is properly
con󰄈gured, installed and maintained in good working order. Laser marking certain
materialsemitsdangerousfumesand󰄈neparticlesthatmaydamagehealth.
Call an approved supplier to install an extraction system that complies with safety
requirements and local regulations.
Fumesareextractedtotheairextractionsystemthroughahoseconnectedtotheopeningatthebackofthe
machine. This hose is not supplied with the machine but with the extractor.
1. Opening for air evacuation hose to air extraction system
2 modes are available:
Headmode(extractionathead):Moste󰘲cient
modebutrequiresapowerfulvacuumextraction
system
General mode (general extraction): Used to
adapt an extraction system that has a good
󰘱owratebutnotmuchsuction.Anairintakeis
provided in the double door.
Avoid combining the 2 modes.
1
