Preventive maintenance
6. Setting point zero (Origin)
The screen below appears:
L01 SETUP
FPGA X.X
The machine emits an audible signal. The following screen is displayed for 3 seconds:
<< GRAVOGRAPH >>
FPGA X.XX
LCD SOFT X.XX
32 Mo BOOT X.XX
1. While this screen is displayed, press the key:
2. Select the following menu:
LASER SETTINGS
TICKLE
RE-ALIGN MACHINE
USING TIME XXX
3. Tocon󰄈rm,pressthekey:
4. Select the following menu:
X-Y ADJUSTMENT
Z ADJUSTMENT
ALIGNMENT MODE
5. Tocon󰄈rm,pressthekey:
Theheadgoesbacktotheorigin(topleftcorner).Thepointerislit(Red).
The screen below appears:
X-Y ADJUSTMENT
JOYSTICK X-Y
X X.XX Y X.XX
6. Position a plate on the table (top left corner).
7. Set the laser pointer to the top left corner of the plate (Up - Down - Left - Right arrows).
8. Press the key. Keep the key(s) pressed until the head returns to the origin (top left corner).
