M. Using the machine
Example:Engravingakeyring
1. Switching on the PC / Switching on the machine
1. Switch on the PC.
2. Wait until start-up is complete.
3. Switch on the machine.
2. Creating the composition
1. Adjustthepagesizetothemaximumsizeoftheengravingareainthegraphicssoftware(LS900
ENERGY / LS900 IQ / LS900 XP: 610 mm (24.016 in) x 610 mm (24.016 in)).
2. Enter the text to be marked. It should have a black 󰄈ll and no contour.
Example: Enter "ABCDE".
3. Position the text in the top left corner of the page, depending on the position of the keyring on the
engraving table.
Screen (PC)
ABCDE
3. Setting the driver properties
Refer to the manual (L-Solution driver).
