GRAVOGRAPH LS900 XP - Autofocus Adjustment Procedure Steps

65
M_LS900 XP IQ Energy_EN_B
Preventive maintenance
5. Autofocus adjustment
Toadjusttheautofocus,themachinemustbe󰄈ttedwitha2inlensandtheusermustonlyusethe
gage marked 2".
Removeallthetools.Removeanyobjectfromthetable.Theheadhastomoveathigh
speedtowardsthecenterofthetableinordertoperformtheadjustment.
1. Switcho󰓐themachine.
2. Close the door of the machine.
3. Switch on the machine.
The screen below appears:
L01 SETUP
FPGA X.X
The machine emits an audible signal. The following screen is displayed for 3 seconds:
<< GRAVOGRAPH >>
FPGA X.XX
LCD SOFT X.XX
32 Mo BOOT X.XX
4. While this screen is displayed, press the key:
5. Select the following menu:
LASER SETTINGS
TICKLE
RE-ALIGN MACHINE
USING TIME XXX
6. Tocon󰄈rm,pressthekey:
7. Select the following menu:
X-Y ADJUSTMENT
Z ADJUSTMENT
ALIGNMENT MODE
8. Tocon󰄈rm,pressthekey:
The head moves towards the middle of the engraving table. An autofocus is performed automatically.
