Model 11-R

GRIMM AEROSOL TECHNIK GmbH & Co.KG Seite 57 von 83

Example 3:

Normal data presentation in measuring mode:

P 14 10 13 15 59 5 100 0 130 35 6 4 0 65 85

6 5 190 51.9 20.6

C0: 31919 14509 6595 2960 1210 510 250 170

C0; 90 60 40 40 30 25 15 15

c0: 9 4 2 2 2 1 1 1

c0; 1 0 0 0 0 0 0 0

Data presentation in service mode with brief explanation of the P-line values:

Year Mon Day Hr Min Loc GF Err Qbatt Im UeL Ue4 Ue3 Ue2 Ue1

Iv P_Weight P_Vol{l} rH_i Temp_i GPS-Position

P _14 10 13 12 56 1 0 0 100 25 64 4 0 0 0

6 217 375 36.2 33.6 N51.6279 E12.3962 H97

C_: 132940 77350 48435 22270 9325 4610 3210 1795

C_; 1305 1050 765 575 385 280 195 131

c_: 131 82 68 49 33 20 13 10

c_; 7 4 2 1 1 0 0 0
