Grimm Mini-LAS 11-R User Manual

Model 11-R
GRIMM AEROSOL TECHNIK GmbH & Co.KG Seite 73 von 83
7.2 Technical data
7.2.1 Nominal rating of the 11-R model series
Power supply
-Battery: 11.1VDC/4.4Ah, fully charged for 4-8 hours of continu-
ous operation, depending on the operating conditions;
-18VDC power supply (U
out
): 1112C, 100-240VAC (U
in
) , 47-
63Hz, 2.5 A (output)
Maximum current Mini-LAS:
Battery discharged 1.2A
Battery fully charged 0.45A
Fields of application:
For indoor use
Maximum elevation:
1000 m. 2000 m with individual readjustment of the volume flow
per terminal programme with the help of a volume measuring
device, e.g. Drycal or Gilibrator.
Temperature range (in operation):
+4 to +40 °C, relative humidity < 95 % (non-condensing)
Temperature range (storage and
transportation):
-20 to +50 °C, relative humidity < 90 % (non-condensing)
Maximum relative humidity (in
operation):
Relative humidity < 95% (non-condensing)
Maximum relative humidity (stor-
age and transportation):
Relative humidity < 90% (non-condensing)
Temperature of the sample air:
+4 to +40 °C, relative humidity < 95 %, nor corrosive or explo-
sive gases
Pressure range of the sample air:
At normal pressure the volume flow is set to 1.2 litres per mi-
nute.
For sites more than 1000m above sea level, the volume flow
should be readjusted.
0 to -50 hPa (short term). At overpressure (max. +100 hPa) and
for extended measurements with higher underpressure (max. -
100 hPa), the sample air return has to be used.
Sample air return:
Present, discharge on the left side of the device
7.2.2 Technical data for the 11-R model series
Laser:
Wavelength: = 660 nm Output: P
max
= 40mW
P
nom
= 0, 5/32 mW CW (multiplex)
Size channels:
The specified channel thresholds {µm} apply for a counting effi-
ciency of 50% with mono-dispersive latex aerosol, 31 channels
of the optical aerosol spectrometer, lower channel limits:
0.25/ 0.28/ 0.3/ 0.35/ 0.4/ 0.45/ 0.5/ 0.58/ 0.65/ 0.7/ 0.8/ 1.0/ 1.3/
1.6/ 2/ 2.5/ 3/ 3.5/ 4/ 5/ 6.5/ 7.5/ 8.5/ 10/ 12.5/ 15/ 17.5/ 20/ 25/
30/ 32 {µm}
Particle concentration:
1 to 2,000,000 particles per litre
Particle mass:
0.1 to 100,000 µg/m³
Reproducibility:
±3% across the entire measuring range
Sample volume flow:
1.2 l/min, ±5% constantly controlled
Purge air volume flow:
0.3 l/min, constantly controlled Automatic follow-up cleaning in
standby mode
