Grimm Mini-LAS 11-R User Manual

Model 11-R
GRIMM AEROSOL TECHNIK GmbH & Co.KG Seite 74 von 83
Sample collector:
47 mm PTFE round filter (no supporting material)
GRIMM order no.: 1113A
Operation:
With membrane keyboard or via PC with interfaces (RS-232,
USB, Ethernet, Bluetooth via Windows software or
HyperTerminal programme and control commands
Display:
2 x 16 alphanumeric characters, light-emitting (OLED)
Self-test:
Automatically on start-up
Measuring time intervals:
Configurable: 6 sec. 1 min, 5 min, 10 min, 15 min, 30 min, 60 min
through Windows software or HyperTerminal
Storage interval:
Configurable: 6 sec., 1 min, 5 min, 10 min, 15 min, 30 min,
60 min
(for 31 channels) through Windows software or HyperTerminal
Communication:
Via PC and RS-232 interface, also RS-232 on USB and
Bluetooth or network
Display data output:
Dust measurements or particle concentration as rolling average
mean value for one minute or mean values with corresponding
sample volumes. Alarm values, battery charge level,
gravimetric factor, measuring location number, date and time,
measurements of the optional accessories (sensors)
Data output:
Via PC and interfaces (RS-232, USB, Ethernet, Bluetooth)
Analogue inputs:
3 x (0-10V), resolution 10-bit (approx. 10 mV). Display with
calibration factors that can be changed and editable texts.
Data interface:
ASCII: RS-232 (9600 baud, 8-bit, no parity, 1 stop bit,
software protocol: Xon/Xoff)
Data storage SD card
4 GB, for storing measurements and the following
data: date, time, measuring location number, gravimetry
factor, error code, battery charge level, motor current, GPS
data, internal moisture and temperature, and the analogue
values of the external sensors (1 to 3)
USB stick data storage:
Up to 4 GB
Dimensions LxWxH:
32 x 18 x 7 (cm)
Weight:
1.7 kg + 0.7kg Li-Ion battery
Colour:
Grey housing (RAL 7048)
Memory functions:
The measuring mode last selected in standby mode is saved
in the device.
In case of power loss during a measurement, all mean values
with the corresponding sample volumes are saved so that the
measurement is automatically continued when power is restored.
