16.6.3 Fusibles UL et section conducteur au secteur et moteur
1)
Câble de moteur blindé, câble d'alimentation non blindé.
2)
American Wire Gauge.
Puissance à l'arbre
typique P2
Type de fusible Section max.
conducteur
1)
Bussmann
RK1
Bussmann
J
Bussmann
T
SIBA
RK1
Littel Fuse
RK1
Ferraz-Shawmut
CC
Ferraz-Shawmut
RK1
[kW]
[AWG]
2)
1 x 200-240 V
1,1 KTN-R20 – – – – – – 10
1,5 KTN-R30 – – – – – – 7
2,2 KTN-R40 – – – – – – 7
3KTN-R40–– – – – – 7
3,7 KTN-R60 – – – – – – 7
5,5 – – – – – – – 7
7,5 – – – – – – – 2
3 x 200-240 V
0,75 KTN-R10 JKS-10 JJN-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
1,1 KTN-R20 JKS-20 JJN-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
1,5 KTN-R20 JKS-20 JJN-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
2,2 KTN-R20 JKS-20 JJN-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
3 KTN-R30 JKS-30 JJN-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
3,7 KTN-R30 JKS-30 JJN-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
5,5 KTN-R50 JKS-50 JJN-50 5012406-050 KLN-R50 – A2K-50R 7
7,5 KTN-R50 JKS-60 JJN-60 5012406-050 KLN-R60 – A2K-50R 7
11 KTN-R60 JKS-60 JJN-60 5014006-063 KLN-R60 A2K-60R A2K-60R 7
15 KTN-R80 JKS-80 JJN-80 5014006-080 KLN-R80 A2K-80R A2K-80R 2
18,5 KTN-R125 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R A2K-125R 1/0
22 KTN-R125 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R A2K-125R 1/0
30 FWX-150 – – 2028220-150 L25S-150 A25X-150 A25X-150 1/0
37 FWX-200 – – 2028220-200 L25S-200 A25X-200 A25X-200 4/0
45 FWX-250 – – 2028220-250 L25S-250 A25X-250 A25X-250 250 MCM
3 x 380-500 V
0,55 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
0,75 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
1,1 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
1,5 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
2,2 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
3 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
4 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
5,5 KTS-R30 JKS-30 JJS-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
7,5 KTS-R30 JKS-30 JJS-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
11 KTS-R40 JKS-40 JJS-40 5014006-040 KLS-R40 – A6K-40R 7
15 KTS-R40 JKS-40 JJS-40 5014006-040 KLS-R40 – A6K-40R 7
18,5 KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R50 – A6K-50R 7
22 KTS-R60 JKS-60 JJS-60 5014006-063 KLS-R60 – A6K-60R 2
30 KTS-R80 JKS-80 JJS-80 2028220-100 KLS-R80 – A6K-80R 2
37 KTS-R100 JKS-100 JJS-100 2028220-125 KLS-R100 – A6K-100R 1/0
45 KTS-R125 JKS-150 JJS-150 2028220-125 KLS-R125 – A6K-125R 1/0
55 KTS-R150 JKS-150 JJS-150 2028220-160 KLS-R150 – A6K-150R 1/0
75 FWH-220 – – 2028220-200 L50S-225 – A50-P225 4/0
90 FWH-250 – – 2028220-250 L50S-250 – A50-P250 250 MCM
3 x 525-600 V
0,75 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
1,1 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
1,5 KTS-R10 JKS-10 JJS-10 5017906-010 KTN-R10 ATM-R10 A2K-10R 10
2,2 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
3 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
4 KTS-R20 JKS-20 JJS-20 5017906-020 KTN-R20 ATM-R20 A2K-20R 10
5,5 KTS-R30 JKS-30 JJS-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
7,5 KTS-R30 JKS-30 JJS-30 5012406-032 KTN-R30 ATM-R30 A2K-30R 10
3 x 525-690 V
11 KTS-R-25 JKS-25 JJS-25 5017906-025 KLSR025 HST25 A6K-25R 1/0
15 KTS-R-30 JKS-30 JJS-30 5017906-030 KLSR030 HST30 A6K-30R 1/0
18,5 KTS-R-45 JKS-45 JJS-45 5014006-050 KLSR045 HST45 A6K-45R 1/0
22 KTS-R-45 JKS-45 JJS-45 5014006-050 KLSR045 HST45 A6K-45R 1/0
30 KTS-R-60 JKS-60 JJS-60 5014006-063 KLSR060 HST60 A6K-60R 1/0
37 KTS-R-80 JKS-80 JJS-80 5014006-080 KLSR075 HST80 A6K-80R 1/0
45 KTS-R-90 JKS-90 JJS-90 5014006-100 KLSR090 HST90 A6K-90R 1/0
55 KTS-R-100 JKS-100 JJS-100 5014006-100 KLSR100 HST100 A6K-100R 1/0
75 KTS-R125 JKS-125 JJS-125 2028220-125 KLS-125 HST125 A6K-125R 1/0
90 KTS-R150 JKS-150 JJS-150 2028220-150 KLS-150 HST150 A6K-150R 1/0
