Fig 2.1 Bottom board installation pattern
Fig 2.2 Panel installation pattern
Fig. 2.3 is installation interval for one servo unit and Fig. 2.4 is for servo units. The actual
interval for installation should be larger as possible as to get a good heat radiation.
Fig. 2.3 Installation interval for a single servo unit
Installation interval
