GSK DA98B - 4.2 Parameter function

GSK CNC Equipment Co., Ltd.
28
PA 25 Internal speed 2 S
-30000~30000 -500 0.1rpm
PA 26 Internal speed 3 S -30000~30000 2000 0.1rpm
PA 27 Internal speed 4 S -30000~30000 -3000 0.1rpm
PA 28 Speed in orientation S
0～30000
5000 0.1rpm
PA 29 Max. speed of analog instruction S
0～31000
25000 0.1rpm
PA 30 Conversion numerator for linear speed P,S
1～32767
10
PA 31 Conversion denominator for linear speed P,S
1～32767
1
PA 32 Decimal point for linear speed P,S
0～5
3
PA 34 Internal CCW torque limit P,S
0～300
300 %
PA 35 Internal CW torque limit P,S
-300～0
-300 %
PA 36 External CCW torque limit P,S
0～300
300 %
PA 37 External CW torque limit P,S
-300～0
-300 %
PA 38 JOG torque limit of trial speed S
0～300
300 %
PA 52 Latency for hold stop P,S
0-32767 0 ms
4.2 Parameter function
No. Name
Function
Parameter
range
PA 00 Password
It is used for parameter not to be modified by mistake. Set it for 315
when a parameter is needed to set. After debugging, set it for 0 to
ensure it not to be modified by mistake later.
0~9999
PA 01 Motor type code The motor models Corresponding to PA01 are as following, refer to
Section 4.3 for details.
PA01 Motor model
12 110SJT-M060D
17 130SJT-M100D
19 130SJT-M150D
35 110ST-M04030H
46 130ST-M06025H
0~63
PA 02 Software version
① Software version can be seen but can not be modified.
Ver 2.04
PA 03 Initial display state
(Display state
selection after servo
unit power is
switched on)
0： Motor speed display;
1： Low 5-bit digit display of current orientation;
2：High 5-bit digit display of current orientation;
3：Low 5-bit digit display of orientation instruction(instruction pulse
accumulation );
4：High 5-bit digit display of orientation instruction(instruction pulse
accumulation );
5：Low 5-bit digit display of orientation deviation;
6: High 5-bit digit display of orientation deviation;
0~20
