The GPP-3060/GPP-6030 regulated DC power
supply series are adjustable, multifunctional
work stations. It has three independent
outputs: two with adjustable voltage levels and
one with fixed level selectable from 1.8V, 2.5V,
3.3V and 5V.
It can be used for logic circuits where various
output voltage or current are needed, and for
tracking mode definition systems where plus
and minus voltages with insignificant error are
required.
The three output modes of it, independent,
tracking series, and tracking parallel, can be
selected through pressing the TRACKING key
on the front panel. In the independent mode,
the output voltage and current of each channel
are controlled separately. The isolation degree,
from output terminal to chassis or from output
terminal to output terminal, is DC500V.
In the tracking modes, both the CH1 and CH2
outputs are automatically connected in series
or parallel; no need to connect output leads. In
the series mode, the output voltage is doubled;
in the parallel mode, the output current is
doubled.
