GW Instek GPP-3060 - Key Function Description

BASIC OPERATION
87
Key Function Description
Input/Output Mode:
Key
Function
Operation Result
F1
Data Line
Select object to be set from D0 to F4
F2
Enable
Set to Enable or Disable function of the port
F3
Mode
Set which mode to adopt: Input Mode or
Output Mode
F4
Channel
Select corresponding channel: F1(CH1), F2
(CH2), F3 (CH3)
F5
More
F6
Return
F5 (More) under Input Mode setting:
Key
Function
Operation Result
F1
Type
Select trigger type: F1(RiseEdge), F2
(FallEdge), F3 (Hi-Level), F4 (Lo-Level), ,
F5(States Input)
* "States Input" equivalent to edge trigger
(RiseEdge + FallEdge)
F2
Response
Set result after trigger response:
F1(Output) sets as ON, OFF or reverse
Toggle
F2 (PWR.Mode) sets channel as power mode
F3 (Load Mode) set channel as load
CV/CC/CR mode
F4(Track Mode) sets tracking mode of
CH1/CH2. This function will only work if
channels CH1 and CH2 are selected
simultaneously(only source mode),GPP-1326
does not have such function.
F3
Sensitivity
Set sensitivity of trigger: High/Middle/Low
F4
F5
F6
Return
