Current
Under the Sequence function, press
F2 (Edit) button followed by
selecting F4 (Current). The setting on
LCD is activated and appears in red
font color . Use
number pad to set the parameters
directly and then press the F1 (A) or
F2 (mA) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
Time
Under the Sequence function, press
F2 (Edit) button followed by
selecting F2 (Time). The setting on
LCD is activated and appears in red
font color . Use
number pad to set the parameters
directly and then press the F1
(Second) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
Construct Templet
Description
This function can be used for practical applications
when different voltage waveforms are required to be
output. Users can edit the output waveform according
to their needs. The built-in Sine, Pulse, Ramp, Stair Up,
Stair Dn, Stair UpDn, Exp Rise, Exp Fall waveforms are
practical per usage.
Parameter
Description
Object
To edit Voltage or Current
Type
Select the buit-in waveforms
including Sine, Pulse, Ramp, Stair
Up, Stair Dn, Stair UpDn, Exp Rise,
