GPP-3060/6030 User Manual
66
It is necessary to output a series of pulse in real
applications. This function is available when
voltage is constant. Output waveform can be
edited per user’s preference. The amplitude
range of the output waveform is the output
voltage range of power supply. The setting
range for output waveform duration is 1s ~
Infinite (duration calculation: Time x Groups x
Cycles) and the resolution is 1s.
Note: This feature is applicable to both CH1
& CH2.
Cycle number, 1 represents a cycle of
single period. 2 represents a cycle
with 2 periods, and so on. The range
is from 1 to 9999 or Infinite.
The number (No.) to start execute. 0
indicates the execution starts from
the group 0, while 1 indicates it
begins from the group 1, and so on.
The range is from 0 to 2047.
