APPENDI
X
217
Storage
Environment
TEMPERA
TU
RE: -1
0˚C ~ 70˚C
HUMIDITY:
≤
7
0%
Power input
AC 100V/120V/220V/23
0V±10%
,
50/60Hz
consumption
900V
A,680W
Accessories
CD User manual x1,
Quick Start manual
x1,
Power Code x1
T
est lead
:
GTL
-104A x 3
(Europe) T
est lead
:
GTL
-204A x 3, GTL-
201
A x1
Dimensions
213 (W) x 145 (H) x
362 (D)
mm
W
eig
ht
Approx. 10
kg
Optional Ac
cessories
USB C
able
GTL
-246
USB 2.0, A-B type
216
218
Table of Contents
Table of Contents
3
Safety Instructions
7
Safety Symbols
7
Safety Guidelines
8
Power Cord for the United Kingdom
11
Overview
13
Introduction
13
Key Features
16
Front Panel
18
Rear Panel
24
Constant Voltage/Constant Current Crossover Characteristics
26
Getting Started
27
Start up
28
Load Connection
29
Select Front/Rear Panel Output
31
Turning the Output On/Off
32
Basic Operation
33
Display Change
34
Source Function
37
Independent Output Mode
43
Tracking Series and Tracking Parallel Modes
45
Load Function
50
Sequence Function
54
Set Sequence Output
54
Set Group Parameter
57
Construct Templet
58
Menu Tree
61
Save and Recall
63
Delay Function
66
Set Delay Output
66
Set Group Parameter
69
Menu Tree
72
Save and Recall
74
Monitor Function
77
Set Monitor
77
Recorder Function
81
Set Recorder
81
External I/O Control
85
Key Function Description
87
File Operation
89
Save/Recall
90
Restore Factory Default Settings
93
System Settings
94
System Information
95
System Settings
96
Firmware Upgrading
98
Description of Using Flash Drive
99
Remote Control
101
Connection Usage
103
Usb
106
Gpib
108
Lan
110
Command Syntax
116
Command List
120
Measurement Instructions
120
Display Functions
120
Output Commands
120
Source and Load Commands
121
Status Commands
126
System Commands
127
System Related Commands
128
IEEE488.2 Common Commands
129
Command Details
130
Measurement Commands
130
Display Commands
132
Output Commands
134
Source and Load Commands
139
Status Commands
183
System Commands
190
System Related Commands
199
SCPI Status Registers SCPI
200
Event Registers
202
Enable Registers
202
Status Byte Register
202
Standard Event Register
204
Status Byte Register Commands
205
Standard Event Register Commands
206
Other Status Register Commands
208
Errors
209
Error Message
209
Command Errors
209
Appendix
213
Replacing the Fuse
213
Specifications
214
Optional Accessories
217
