BASIC
OPERA
TI
ON
45
Tracking Series and Tracking Parallel Modes
Description
T
racking series opera
tion doubles the V
oltage
capacity of the GPP by
internall
y
connecting CH1
(Master) and CH
2 (Slave) in seri
es
and
combining
the output to a single chan
nel.
CH1 (Master) controls
the combined V
oltage output
leve
l.
T
racking series w
ithout common terminal
F
ront
panel
connection
Rear pane
l
with sense
connection
Load
+
-
Loa
d
44
46
