GPP-3060/6030 User Manual
130
Command Details
When using commands to select a specific channel, [1] stands for
CH1, [2] stands for CH2. "1" can be omitted when you want to
select CH1 as it is selected by default. However if you wish to select
CH2, "2" must be selected.
Measurement Commands
Command
:MEASure[1|2|3] :<function>?
Function
Performs a “READ?” query on the specified
measurement function.
Description
<function>
CURRent[:DC]:Measures the current.
VOLTage[:DC]:Measures the voltage.
POWEr[:DC]:Measures the power.
Example
:MEASure2:CURRent?
Reads back the CH2 current value.
Note
About CH3 , The query voltage will return the set
value, current and power will return zero.
Command
:MEASure[1|2|3]:ALL?
Function
Query the all measurement functions.
Example
:MEASure2:ALL?
Reads back the CH2 voltage ,current and power
value.
Note
CH3 will return: voltage setting,0,0.
Command
:MEASure:<function>:ALL?
Function
Query the specified measurement function in all
channels.
