BASIC OPERATION
57
Set Group Parameter
Description
Each Group consists of Voltage, Current and
Time. Therefore, properly confirm parameter of
each group is correct before setting Sequence
output.
Parameter
Description
No.
Voltage
Current
Time
Group number. Maximum 2047
Voltage setting of each group.
Current setting of each group.
Execution duration of each group.
Range: 1S – 300S
Parameter
Setting
No.
Under the Sequence function, press
F2 (Edit) button followed by
selecting F1 (No.). The setting on
LCD is activated and appears in red
font color . Use number
pad to set the parameters directly
and then press the F1 (Done) button
to confirm; or use arrow keys along
with scroll wheel to complete the
setting. The F4 (Page Up)key and F5
(Page Down) key can jump directly
to the previous or next page,each 8
groups is a Page.
Voltage
Under the Sequence function, press
F2 (Edit) button followed by
selecting F3 (Voltage). The setting on
LCD is activated and appears in red
font color . Use
number pad to set the parameters
directly and then press the F1 (V) or
F2 (mV) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
