GPP-3060/6030 User Manual
214
Specifications
The specifications apply under the following conditions: The GPP is
powered on for at least 30 minutes, within +20°C -+30°C.
Power Mode
Output
Rating
CH1/CH2
Independent
0 - 30.000V , 0 - 6.0000A (GPP-3060)
0 - 60.000V , 0 - 3.0000A (GPP-6030)
CH1, CH2
Series
0 - 60.000V , 0 - 6.0000A (GPP-3060)
0 - 120.000V , 0 - 3.0000A (GPP-6030)
CH1, CH2
Parallel
0 - 30.000V , 0 - 12.0000A (GPP-3060)
0 - 60.000V , 0 - 6.0000A (GPP-6030)
Voltage
Line
regulation
0.01% + 3mV
Load
regulation
0.01% + 5mV (rating current 10A)
Ripple &
noise
(5Hz-1MHz)
1mVrms,
Transient
recovery
time
10s)
(50% load changeminimum load 0.5A)
Temperature
coefficient
300ppm/°C
Current
Line
Regulation
0.01% + 3mA
Load
Regulation
0.01% + 3mA
Ripple &
noise
2mArms
Tracking
Operation
Tracking
error
0.1% +10mV of Master(GPP-3060)
0.2% +20mV of Master(GPP-6030)
(No Load, with load add load regulation200mV)
Parallel
regulation
Line: 0.01% + 3mV
Load: 0.01% + 5mV (rating current 10A)
0.02% + 5mV (rating current > 10A)
Series
regulation
Line: 0.01% + 5mV
Load: 200mV
Ripple &
noise
2mVrms(5Hz-1MHz)
