BASIC OPERATION
59
Exp Fall.
Max
Value
Set the max. value of waveform
voltage/current
Min
Value
Set the min. value of waveform
voltage/current
Start
Set the initial group number of
waveform. Maximum: 2037
Points
Select the required points. Range: 10-
2047
Inverted
Invert the selected waveform
Parameter
Setting
Object
Press the F1 (Object) button to select
Voltage /Current
in turn. Simply stop at the
parameter which is in need of
setting.
Type
After pressing the F2 (Type) button,
select the button corresponding to
the applicable waveform. Up to 8
default waveforms are available for
selection.
Max
Value
Press the F3 (Max Value) button. The
setting on LCD will be activated and
appears in red front color
. Use number pad to set
the parameters directly and then
press the F1 (V/A) or the F2
(mV/mA) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
