GW Instek GPT-12004 User Manual

GPT-10000 Series User Manual
274
AC Withstanding Voltage
Output Voltage Range
0.050kV~ 5.000kV
1
Output Voltage Resolution
1V
Output Voltage Accuracy
 (1% of setting +5V) with no load
Maximum Rated Load(Table1)
GPT-15XXX
500VA (5kV/100mA)
GPT-12XXX
200VA (5kV/40mA)
Maximum Rated Current
GPT-15XXX
100mA
0.001mA~10mA(0.05kVV0.5kV)
0.001mA~100mA(0.5kVV5kV)
GPT-12XXX
40mA
0.001mA~10mA(0.05kVV0.5kV)
0.001mA~40mA(0.5kVV5kV)
Output Voltage Waveform
Sine wave
Frequency
50 Hz / 60 Hz
Voltage Regulation
± (1% +5V)[Maximum rated load no load]
Voltmeter Accuracy
± (1% of reading+ 5 V)
Current Measurement Range
GPT-15XXX
0.001mA~100.0mA
GPT-12XXX
0.001mA~40.00mA
Current Best Resolution
GPT-15XXX
1µA
1µA (1µA~9.999mA)
10µA(10.00mA~99.99mA)
100µA(100.0mA)
GPT-12XXX
1µA
1µA (1µA~9.999mA)
10µA(10.00mA~40.00mA)
Current Measurement
Accuracy
± (1.5% of reading+30µA)
Judgment Accuracy
± (3% of setting+30µA)
Window Comparator Method
Yes
ARC DETECT
Yes
Rise-time Control Function
Yes
RAMP TIME (Rise Time)
0.1~999.9s
Fall-time Control Function
Yes
RAMP DOWN Time
0.0~999.9s
TIMER (Test Time)²
OFF, 0.3s~999.9s
TIMER Accuracy
+/-(100ppm+20ms)
GND
ON/OFF
WAIT TIME
0.0~999.9s
1
At least ramp 0.3 seconds is needed to reach a set voltage of 50V/10mA.
2
Timer can only be turned off when the upper current is set below 30mA. (GPT-12XXX)
3
Timer can only be turned off when the upper current is set below 80mA. (GPT-15XXX)
