APPENDIX
275
DC Withstanding Voltage
Output Voltage Range
0.050kV~ 6.000kV¹ (0.050kV~12kV for GPT-15012)
Output Voltage Resolution
1V
Output Voltage Accuracy
±(1% of setting +5V) With no load
Maximum Rated Load
GPT-15XXX
100W(5kV/20mA)
GPT-15012
120W (12kV/10mA)
GPT-12XXX
50W(5kV/10mA)
Maximum Rated Current
GPT-15XXX
20mA
0.001mA~2mA(0.05kVV0.5kV)
0.001mA~20mA(0.5kVV6kV)
GPT-15012
GPT-12XXX
10mA
0.001mA~2mA(0.05kVV0.5kV)
0.001mA~10mA(0.5kVV12kV)
10mA
0.001mA~2mA(0.05kVV0.5kV)
0.001mA~10mA(0.5kVV6kV)
Voltmeter Accuracy
± (1% of reading+ 5 V)
Voltage Regulation
± (1% +5V)[Maximum rated load ->no load]
Current Measurement Range
GPT-15XXX
0.001mA- 20.00mA
GPT-15012
GPT-12XXX
0.001mA-10.00mA
0.001mA-10.00mA
Current Measurement Best
Resolution
GPT-15XXX
GPT-15012
0.1µA
0.1µA (0.1µA~999.9µA)
1µA (1µA~9.999mA)
10µA (20.00mA)
10µA (10.00mA)
GPT-12XXX
0.1µA
0.1µA (0.1µA~999.9µA)
1µA(1µA~9.999mA)
10µA(10.00mA)
Current Measurement
Accuracy
±(1.5% of reading+3µA) when I<1mA
±(1.5% of reading+30µA) when I≥1mA
Judgment Accuracy
± (3% of setting+30µA)
Window Comparator Method
Yes
ARC DETECT
Yes
Rise-time Control Function
Yes
RAMP TIME (Rise Time)
0.1~999.9s
Fall-time Control Function
Yes
RAMP DOWN Time
0.0~999.9s
TIMER (Test Time)
OFF, 0.3s~999.9s
TIMER Accuracy
+/-(100ppm+20ms)
GND
ON/OFF
WAIT TIME
0.0~999.9s
