GW Instek PSU 100-15 User Manual

PSU Series User Manual
172
F-75 = 0 or 1
F-75 = 0
Set the UART TCP to SCPI.
F-75 = 1
Set the UART TCP to TDK
(emulation mode).
F-76 = 00~30
Set the address of the master unit.
It must be a unique address
identifier.
F-77 = 0
Disable Multi-Drop mode.
7. Press the Function key to enter the
Normal configuration settings for
the slave(s).
Page 112
Set the following settings:
F-70 = 2~3
Set the slave unit to RS485.
Connect to
PC using
F-70
(Master)
F-70
(All slave)
RS232
1
2
RS485 4W
2
2
RS485 2W
3
3
F-71 = 0~7
Set the baud rate (make all units,
including the master, the same
baud). See page 165.
F-72 = 1
Set to 8 data bits.
F-73 = 0
Parity to none.
F-74 = 0
1 Stop bit.
F-75 = 0~1
F-75 = 0
Set the UART TCP to SCPI.
F-75 = 1
Set the UART TCP to TDK
(emulation mode).
Set the uart tcp (make all units,
including the master, the same uart
tcp). See page 165.
