GW Instek PSW Series Programming Manual

PSW Series User Manual
24
Configure the Ethernet Interface
The Ethernet interface can be configured for a number of different
applications. Ethernet can be configured for basic remote control or
monitoring using a web server.
The PSW series supports DHCP connections so the instrument can
be automatically connected to an existing network. Alternatively,
network settings can also be manually configured.
Background
The Ethernet interface is used for remote
control and monitoring over a network.
Ethernet
configuration
Settings
MAC Address
(display only)
LAN
DHCP IP Address
Subnet Mask Gateway
DNS Address Sockets Active
Web Server Active Web Password Active
Web set password 0000~9999 (default 0000)
Connection
1. Connect an Ethernet cable from
the network to the rear panel
Ethernet port.
DHCP
Connection
Example
2. Use the Following configuration settings to use
Dynamic Host Configuration Protocol. The
following settings will also automatically assign
an IP address.
3. Press the Function key to enter the
following LAN configuration
settings.
Page 17
F-37 = 1 Turn DHCP to enable
F-59 = 1 Turn the web server on
Note
It may be necessary to cycle the power or refresh
the web browser to connect to a network.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
