H3C S1526 Smart Ethernet Switch Chapter 2
Web-based Configuration
2-18
shared among the member ports. This feature increases
bandwidth and enhances connection reliability.
Three load distribution algorithms for physical links are
available to implement port trunking: source MAC-based (SA),
destination MAC-based (DA), and source & destination
MAC-based (SA+DA).
II. Ethernet port trunking configuration
Click [Port/Trunk] to enter the [Trunk Algorithm] page, as
shown in
Figure 2-13. Follow these steps:
1) Select a link distribution algorithm in the [Trunk
Algorithm] drop-down list.
2) Set the quantity of trunk groups and the member
port(s) in each trunk group by selecting from the
single-selection boxes.
3) Click <Apply> to complete the configuration.
