H3C S1526 User Manual

User Manual
H3C S1526 Smart Ethernet Switch
Chapter 3 Configuration Through
Console Port
3-1
Chapter 3 Configuration Through
Console Port
3.1 Building Configuration Environment
Through Console Port
I. Connecting the switch to the console terminal
As shown in
Figure 3-1, to build a local configuration
environment, simply connect the serial port on a PC (or a
console terminal) to the console port of the switch by using a
console cable.
Figure 3-1 Build configuration environment through
conso
le port
II. Configuring terminal parameters
1) Click [Start/Programs/Accessories/Communications],
and run the terminal emulation program
