User Manual
H3C S1526 Smart Ethernet Switch Chapter 2
Web-based Configuration
2-19
Note:
z If you set the VLAN properties for a member port of a trunk
group, the VLAN properties of the other ports in that trunk
group will change accordingly.
z If port mirroring is enabled on a port or port isolation is
enabled on the corresponding VLAN, port trunking cannot
be configured on that port.
z Port trunking is not enabled for ports in the normal group.
z Each trunk group supports 2 to 4 ports.
z For trunking ports, the duplex mode must be full duplex, and
the speed setting must be the same and cannot be
auto-negotiation.
Example: As shown in Figure 2-13, set ports 01, 02, 03
and 04 in trunk group 1, and select [Source & Destination
MAC-based] as the trunk algorithm.
