H3C S1526 Smart Ethernet Switch Chapter 2
Web-based Configuration
2-32
Item Description
VLAN
Query
To query a VLAN, enter its VLAN ID in the
[VLAN ID] input box under [VLAN query] and
click <QUERY>. The matched VLAN, if it
exists, will be displayed.
II. Create
Click the <New> button on the right of the page shown in
Figure 2-21 to enter a VLAN creation page as shown in Figure
2-22. The icons on the page and their descriptions are listed in
Table 2-8.
Table 2-8 VLAN icon description
Icon Description
This port does not belong to this VLAN.
This port belongs to this VLAN and the
outgoing packets from this port will be tagged.
This port belongs to this VLAN and the
outgoing packets from this port will be
untagged.
Take the following steps:
1) Enter the VLAN ID you want to create in the [VLAN ID]
text box in the page, as shown in
Figure 2-22.
2) To change the VLAN properties of a port, click the icon
below each port. To perform configuration to all ports,
click the icon below “All”.
