User Manual
H3C S1526 Smart Ethernet Switch Chapter 2
Web-based Configuration
2-33
3) You can set the port isolation function for the VLAN.
Select the <Enable port isolation> check box at first,
and then input the uplink port number. The uplink port
is used to connect the upper-level switch or router.
This step is optional.
4) Click the <Apply> button and continue to configure
PVID of the VLAN member ports. Refer to section
2.6.2 IV. Configuring PVID” for PVID configuration.
Caution:
If port isolation is enabled for a VLAN, the member ports of that
VLAN cannot belong to any other VLAN.
For example, as shown in
Figure 2-22, create a VLAN with
the ID 10, set ports 3, 4, 5, and 6 as member ports of VLAN 10,
untag outgoing packets on ports 3 and 4, and tag outgoing
packets on ports 5 and 6.
