User Manual
H3C S1526 Smart Ethernet Switch Chapter 2
Web-based Configuration
2-35
Note:
z A VLAN ID can range from 2 to 4094. VLAN 1 is the default
management VLAN of the switch and it includes all ports by
default. VLAN 1 cannot be deleted.
z After you create a VLAN, configure PVID of the VLAN in the
“PVID configuration” page. Refer to section
2.6.2 IV.
“Configuring PVID” for PVID configuration.
z Tag: Every Ethernet frame in an IEEE802.1Q-based VLAN
has a tag, which contains information of frame priority and
of the VLAN that this frame belongs to, and so on. Generally
if a port is connected to a PC, frames do not need to be
tagged on this port; if it is connected to another IEEE
802.1Q-compliant switch, it is recommended to tag frames.
z Refer to Chapter 4 “Typical Configuration” for information
about 802.1Q VLAN configuration.
III. Modify
Click the VLAN ID in the page shown in
Figure 2-21 to
enter the [VLAN Modification] page as shown in
Figure 2-23,
where you can modify the settings to that VLAN. Refer to
section
2.6.2 II. “Create” for interface description and
configuration modification. Skip the first step and follow all the
rest steps described in section
2.6.2 II. “Create”.
