1-8
Item S5130S-28TP-EI S5130S-52TP-EI
S5130S-28S-EI
S5130S-28S-EI-M
S5130S-52S-EI
S5130S-52S-EI-M
Minimum
power
consumption
10 W 20 W 10 W 19 W
Maximum
power
consumption
24 W 42 W 24 W 44 W
Chassis
leakage
current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Melting
current of
power
supply fuse
2 A/250 V 3.15 A/250 V 2 A/250 V 3.15 A/250 V
Cooling
system
Passive cooling
Using fixed fan trays
to draw ambient air
in from the left side
and right side of the
chassis and exhaust
heated air out from
the power supply
side.
• Models with
product codes
LS-5130S-28S
- EI-H1 and
LS-5130S-28S
-EI-H1-GL:
Passive
cooling.
• Other models:
Using fixed fan
trays to draw
ambient air in
from the left
side, right side,
and port side of
the chassis and
exhaust heated
air out from the
power supply
side.
Using fixed fan trays
to draw ambient air in
from the left side and
right side and exhaust
heated air out from
the power supply side.
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating
humidity
5% to 95%, noncondensing
Fire
resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Table1-5 Technical specifications for non-PoE switch models (4)
Item S5130S-28F-EI S5130S-52F-EI
Dimensions (H × W × D)
43.6 × 440 × 360 mm (1.72 × 17.32 ×
14.17 in)
43.6 × 440 × 360 mm (1.72 × 17.32 ×
14.17 in)
Weight ≤ 6 kg (13.23 lb) ≤ 6.5 kg (14.33 lb)
Console port
• 1 × serial console port
• 1 × micro USB console port
When both ports are connected, only
the micro USB console port is
• 1 × serial console port
• 1 × micro USB console port
When both ports are connected, only the
micro USB console port is available.
