1-9
Item S5130S-28F-EI S5130S-52F-EI
available.
10/100/1000BASE-T
autosensing Ethernet
port
8 (Each and its corresponding SFP
port form a combo interface.)
2 (Each and its corresponding SFP port
form a combo interface.)
SFP port
24 (The eight highest-numbered
SFP ports form combo interfaces
with their corresponding
10/100/1000BASE-T autosensing
Ethernet ports, respectively.)
48 (The two highest-numbered SFP
ports form combo interfaces with their
corresponding 10/100/1000BASE-T
autosensing Ethernet ports,
respectively.)
SFP+ port 4 4
Power supply slot 2, at the rear panel 2, at the rear panel
Input voltage
CA-70A12:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 290 VAC @ 47 to 63 Hz
PSR75-12A:
• Rated voltage:
 100 VAC to 240 VAC @ 50 or 60 Hz
 240 VDC
• Max voltage:
 90 VAC to 290 VAC @ 47 to 63 Hz
 180 to 320 VDC
PSR150-A1:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
PSR150-D1:
• Rated voltage: –48 VDC to –60 VDC
• Max voltage: –36 VDC to –72 VDC
DC power source for the PSR150-D1 power supply: –48 VDC power source in
the equipment room or an RPS (H3C RPS800-A or RPS1600-A)
Minimum power
consumption
• 1 × CA-70A12: 15 W
• 2 × CA-70A12: 17 W
• 1 × PSR75-12A: 15 W
• 2 × PSR75-12A: 17 W
• 1 × PSR150-A1: 18 W
• 1 × PSR150-D1: 18 W
• 2 × PSR150-A1: 23 W
• 2 × PSR150-D1: 22 W
• 1 × CA-70A12: 26 W
• 2 × CA-70A12 29 W
• 1 × PSR75-12A: 26 W
• 2 × PSR75-12A: 29 W
• 1 × PSR150-A1: 27 W
• 1 × PSR150-D1: 27 W
• 2 × PSR150-A1: 32 W
• 2 × PSR150-D1: 33 W
Maximum power
consumption
• 1 × CA-70A12: 45 W
• 2 × CA-70A12: 48 W
• 1 × PSR75-12A: 45 W
• 2 × PSR75-12A: 48 W
• 1 × PSR150-A1: 48 W
• 1 × PSR150-D1: 51 W
• 2 × PSR150-A1: 55 W
• 2 × PSR150-D1: 57 W
• 1 × CA-70A12: 69 W
• 2 × CA-70A12: 72 W
• 1 × PSR75-12A: 69 W
• 2 × PSR75-12A: 72 W
• 1 × PSR150-A1: 74 W
• 1 × PSR150-D1: 84 W
• 2 × PSR150-A1: 95 W
• 2 × PSR150-D1: 95 W
Chassis leakage current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
Melting current of power
supply fuse
• CA-70A12: 10 A/250 V
• PSR75-12A: 3.15 A/250 V
