80 6LE005550A
Starting, commissioning, operation
4.2 Starting and configuring the circuit breaker
Action Note/Illustration
5
At this stage it is possible to
modify the other protection
settings.
To do this, it is important to
remain in Unlocked mode
63 160
125
100
Note
Check that the entire setting parameters icon to the left of
the setting value remains displayed in the inverted colour
6
Move the navigation joystick
upwards or downwards
to select another setting
parameter.
63 160
125
100
7
Press the centre of the
joystick to confirm the
selection.The display will
immediately ask you to
change the value selected.
63 160
125
100
8
Move the navigation joystick
upwards or downwards to
perform the setting.
63 160
125
100
9
Press the centre of the
joystick to confirm the new
value
63 160
125
100
