816LE005550A
Starting, commissioning, operation
4.2 Starting and configuring the circuit breaker
Action Note/Illustration
10
Repeat steps 5 to 9 to
perform another protection
setting
11
Move the joystick to the left
to exit Unlocked mode and
return to the Main menu.
63 160
125
100
Note
This procedure is used to change the protection settings for the trip unit only. Other
modifications to the settings such as resetting the maximum measurement values,
returning to factory configurations or authorising data write permission, can be
performed via the unlock button.
If there is no movement on the navigation joystick for more than 30seconds, Locked
mode is activated automatically again.
