HALE RSD - Figure 31. AP Impeller R&R; Table 31. AP Impeller R&R Tools and Consumables List

84
Figure 31. AP Impeller R&R
Refer to Table 31 for a list of tools and/or consumables required for this procedure.
Table 31. AP Impeller R&R Tools And Consumables List
Standard Tools
Special Tools
Consumables
PPE (Eye and Hand Protection) 1 3/4-in Torque Limiting Socket
(110 ft-lb [149 Nm])
Shop Rag(s) (As Required)
1 3/4-in Socket and Ratchet Puller Set (See APPENDIX B) Impeller
<FSG–PL-01483, Sheet 4 Item 4>
Cold Cut Chisel Impeller Nut, ZS-274
<FSG–PL-01483, Sheet 4 Item 3>
Flat Blade Screwdriver Cotter Pin
(Impeller Nut To Pump Shaft)
<FSG–PL-01483, Sheet 4 Item 20>
Brush (For Grease) Grease
(See paragraph 5.7.2, page 49)
Hammer
Heavy Wire Cutters
Impact Driver
Pin (or Drift) Punch
Plyers
