16
Edge sanders
HS 950
4.8 Sanding unit
Sanding
sanding roller Ø 110 mm
Sanding belt 2515 x 150 mm
Sanding belt inclination 0–90°
Sanding belt speed
17 m/s (50 Hz)
10 m/s (60 Hz)
Vertical traversing distance 0–150 mm
Oscillating range 5 mm
Oscillating frequency
90 /min (60 Hz)
75 /min (50 Hz)
Technical specifications
4.6 Chip extraction
Extraction connection
Diameter 120 mm
Vacuum, min. 1310 Pa
Volume flow, min. 814 m³/h
4.7 Operation and storage conditions
Operating/room temperature +10 bis +40 °C
Storage temperature –10 bis +50 °C
