Edge sanders
HS 950
Setup and installation
7 Setup and installation
7.1 Safety instructions
Warning! Risk of injury!: Improper assembly and installation can lead to serious physical injury or equipment
damage. For this reason, this work may only be carried out by authorised, trained personnel who are famili-
ar with how to operate the machine and in strict observance of all safety instructions.
• Ensure that there is sufficient space to work around
the machine. Ensure there is ample distance between
the machine and other solid constructions such as a
walls or other machines.
• Keep the work area orderly and clean. Components
and tools that are not put in their correct place or put
away may be the cause of accidents!
• Install the safety equipment according to the
instructions and check that it functions properly.
Warning! Danger! Electric current!: Work on electrical fittings may only be carried out by qualified personnel
and in strict observance of the safety instructions.
Before assembling and installing the machine, check to
make sure it is complete and in good condition.
Warning! Risk of injury!: An incomplete, faulty or damaged machine can lead to serious physical injury or
equipment damage. Only assemble and install the machine if the machine and its parts are complete and
intact.
Attention! Risk of material damage!: Only operate the machine in ambient temperatures from +10°C to
+40°C. If the instructions are not followed, damage may occur to bearings.
7.2 Setup
Installation site requirements:
• Operating/room temperature: +10° to +40°C.
• Ensure that the work surface is sufficiently stable and
has the proper load-bearing capacity.
• Provide sufficient light at the workstation.
• Ensure there is sufficient clearance for or from
neighbouring workstations.
In order to maintain and operate the machine properly, it
must be set up at least 500 mm away from the wall,
parallel to the work direction (measurement X).
Fig. 7-1: Space requirements
