Edge sanders
HS 950
The back cover prevents contact with the rotating abra-
sive belt.
The back cover is fixed to the machine with clamping
screws.
! Clamping screw
Setting up the machine
The data plate displays the following specifications:
• Manufacturer information
• Model designation
• Machine number
• Voltage
• Phases
• Frequency
• Motor power
• Power supply
• Year of construction
• Motor specifications
Fig. 5-2: Data plate
5.2 Data plate
5.3 Safety devices
5.3.1 Rear cover abrasive belt
Fig. 5-3: Rear cover abrasive belt
5.3.2 Infeed fence
Fig. 5-4: Infeed fence
The workpiece stop prevents workpieces from being
thrown backwards.
! Infeed fence
