8 - Technical Specifications
152
Voltage
The sprayer is designed for the following voltage only:
* The blade fuses usually allow up to 50 A for a few seconds before blowing.
€
DANGER! If the tolerances for voltage are exceeded, the electrical system can fail. Risk of fire. Risk of defect or
malfunctioning components.
Power Consumption
Recommended tractor engine output are as follows.
Temperature and Pressure Ranges
Spray Liquid System
Filters
The higher the number of mesh, the finer the filtration.
*depending on selected nozzles
Technical Residue
Residue in the dilutable volume is mentioned in the table below.
The non-dilutable volume varies depending on the boom width and installed options in the fluid system. Worst case
technical residue for the sprayer with the largest tank, largest fluid system and widest spray boom is stated below. Smaller
booms and fluid systems with less options will have less residue.
Voltage 12 V DC. Tolerance: -1.5/+3.0 V DC.
Tolerance for voltage - 1.5 V / + 3.0 V
Current from tractor 40 A peak
Blade fuses on the sprayer 25 A *
Main tank volume (liters) Output (hp) Output (kW)
4500 175 130
5500 190 140
7000 210 160
Operating temperature range 36 - 104° F (2 - 40° C)
Operating pressure for the safety valve 215 psi (15 bar)
Max. pressure on the pressure manifold 290 psi (20 bar)
Max. pressure on the suction manifold 22 psi (1.5 bar)
Filter name / position
Mesh
Size of openings in
the filter
Color EasyClean Cyclone In-Line Tank strainer Nozzle
18 1.00 mm White - - - Yes -
30 0.58 mm Green Yes - - - -
50 0.30 mm Blue Yes - Yes* - Yes*
80 0.18 mm Red Yes Yes Yes* - Yes*
100 0.15 mm Yellow - - Yes* - Yes*
Main tank: 7000 liters
FlexCapacity pump
18 gallons (69 liters)
10.5
15.0
12
