3 - Description
31
Rinsing Tank
One rinsing tank is mounted at the rear of the sprayer behind the main
tank. The tank is made of impact-proof and chemical resistant
polyethylene. It is used for rinsing and flushing of the main tank and
liquid system.
Capacity: approximately 130 gal. (500 liters).
Clean Water Tank
A clean water tank is integrated into the right side cover. It is accessed for
filling at the sprayer’s right side when entering the platform. The ball
valve (A) for water draining is located behind the gray side cover on the
sprayer’s left side.
The water in this tank is for hand washing, cleaning of clogged nozzles
etc. Only fill this tank with clean water.
Capacity: approximately 5 gal. (20 liters).
±
WARNING! Although the clean water tank is only filled with clean
water, this water must NOT be used for drinking.
