3 - Description
42
Drawbars
Rigid Drawbar
The COMMANDER 4500 is equipped with a rigid drawbar. The swivel
hitch (Ø50 mm) is welded to the drawbar.
Suspended Drawbar
For COMMANDER 5500 and 7000 models the drawbar is fully suspended.
The full up and down load from the sprayer to the tractor are transferred
through rubber dampers built into the chassis.
Hydraulic Support Leg CM5500/7000
This support leg supports the sprayer at the front, when it is not coupled to a tractor. When coupling the sprayer to a tractor,
the support leg can be raised or lowered to adjust the sprayer to fit the tractor’s hitch point.
See “Hydraulic Support Leg CM 5500/7000” on page 49 for instructions on how to use the support leg.
Illustration of the support leg (B) when standing on the ground. The
support leg is stored in its retracted position when the sprayer is
attached to the tractor.
SafeTrack
The SafeTrack will make the sprayer automatically follow the tractor’s
back wheels when turning in the field, e.g. at headlands. The SafeTrack
can easily be operated with the hydraulic control unit. SafeTrack has an
integrated safety feature which prevents oversteering when the driving
speed is too high for the given turning radius. If a TankGauge is fitted, the
tank fluid level is also taken into account.
Advantages with SafeTrack:
• A small turning radius
• Better precision when turning
±
WARNING! The operator is responsible for setting the speed limit
for SafeTrack after taking into account the terrain and driving
skills.
Ask you HARDI® dealer if this setting is to be changed.
±
WARNING! During road transport, the drawbar must be aligned in center position. For more instructions, please refer
to the instruction book for the controller in the tractor cabin.
