4 - Sprayer setup
4.3
DANGER! Test of the hydraulic system should be done very cautiously. There may be air trapped in the system
which can cause violent movements of the CANNON spout (optional).
DANGER! Hydraulic leaks: Never use your fingers to locate a leakage in any part of the hydraulic system. Due to
high pressure, hydraulic oil may penetrate the skin.
Ensure that snap couplers are clean before connection!
After having operated the hydraulics and the system has been filled with oil, check tractor’s hydraulic oil level and top up
if necessary.
General info
Hydraulic systems
The tractor hydraulic system requires:
Two single acting hydraulic outlets (one for each hydraulically controlled section valve).
Hydraulic requirements for HC/1 or HC/2 controls
The tractor hydraulic system requires:
One double acting hydraulic outlet for the 180° turning function of the spout.
One double acting hydraulic outlet for the lift cylinder.
Hydraulic requirements for CANNON spout
The tractor hydraulic system requires:
One double acting hydraulic outlet for the lift cylinder.
One double acting hydraulic outlet for individual folding with 4 x 1 multiplier for hydraulic section valves (optional).
The 4 x 1 multiplier kit must be installed before first use (follow the instructions included with the kit). The 4-switch han-
dle needs to be attached to a double acting hydraulic lever on the tractor. The electric switches are used with the
hydraulic lever to control the left and right fold functions of the boom as well as the two hydraulically controlled section
valves.
Hydraulic requirements for B20 Hydraulic boom
