8 - Technical specifications
8.3
Operating temperature range: 36°F to 104°F (2° to 40° C.)
Operating pressure for safety valve: 220 psi (15 bar)
Max. pressure on the pressure manifold: 435 psi (30 bar)
Max. pressure on the suction manifold: 100 psi (7 bar)
Suction filter gauze width: 35 mesh (0.5 mm)
50 mesh (0.3 mm)
80 mesh (0.18 mm)
Pressure filter gauze width:50 mesh (0.3 mm)
80 mesh (0.18 mm)
100 mesh (0.15 mm)
Temperature and pressure ranges
Filters and nozzles
