36
AVR
Specifications
36
AVR
Specifications
Specifications
Audio Section
Stereo power:
two channels driven @ 6/8 ohms, 1kHz,
<0.9% THD
channels driven @ 6/8 ohms, 1kHz, <0.9%
THD
Multichannel power:
two channels driven @ 6/8 ohms, 1kHz,
<0.9% THD
channels driven @ 6/8 ohms, 1kHz, <0.9%
THD
Input sensitivity/impedance: 250mV/27k ohms
Signal-to-noise ratio (IHF-A): 100dB
Surround system adjacent channel
separation:
Dolby Pro Logic/DPLII: 40dB
Dolby Digital: 55dB
DTS: 55dB
Frequency response (@ 1W): 10Hz – 130kHz (+0dB/–3dB)
High instantaneous current
capability (HCC):
Transient intermodulation
distortion (TIM):
Unmeasurable
Slew rate:
FM Tuner Section
Frequency range: 87.5 – 108.0MHz
Usable sensitivity IHF: 1.3µV/13.2dBf
Signal-to-noise ratio (mono/stereo): 70dB/68dB
Distortion (mono/stereo): 0.2%/0.3%
Stereo separation: 40dB @ 1kHz
Selectivity (±400kHz): 70dB
Image rejection: 80dB
IF rejection: 80dB
AM Tuner Section
Frequency range: 520 – 1710kHz (AVR 1710S/AVR 1610S)
522 – 1620kHz (AVR 170S/AVR 160S)
Signal-to-noise ratio: 38dB
Usable sensitivity (loop):
500µV
Distortion (1kHz, 50% mod): 1.0%
Selectivity (±10kHz): 30dB
Bluetooth Section
Frequency range: 2402MHz - 2480MHz
Transmitter power: 0-4dBm
Modulation:
GFSK, π/4-DQPSK, 8-DPSK
Functions: Streaming audio play, supports Bluetooth
3.0, A2DP v1.2, AVRCP v1.4
Video Section
Television format: NTSC (AVR 1710S/AVR 1610S);
PAL (AVR 171S/AVR 161S)
Input level/impedance: 1Vp-p/75 ohms
Output level/impedance: 1Vp-p/75 ohms
Video frequency response (composite
video):
10Hz – 8MHz (–3dB)
HDMI: HDMI 1.4 with 4k x 2k bypass
General Specifications
Power requirement: 120V AC/60Hz (AVR 1710S/AVR 1610S);
220V – 240V AC/50Hz – 60Hz (AVR 171S/
AVR 161S)
Power consumption:
<0.5W (standby);
510W maximum (AVR 1710S/AVR 171S);
450W maximum (AVR 1610S/AVR 161S)
Dimensions (W x H x D):
17-5/16" x 4-3/4" x 11-3/16"
(440mm x 121mm x 300mm)
Weight
(AVR 1710S/AVR 171S): 11 lb (5.1kg)
(AVR 1610S/AVR 161S): 10 lb (4.6kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
AVR 1710S/AVR 171S: 100W per channel,
AVR 1610S/AVR 161S: 85W per channel, two
AVR 1710S/AVR 171S: 100W per channel,
AVR 1610S/AVR 161S: 85W per channel, two
±40 amps (AVR 1710S/AVR 171S);
±29 amps (AVR 1610S/AVR 161S)
37
ENGLISH
AVR
Appendix
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR Source
Digital Audio
Connection
Analog Audio Connection
Video
Connections
Roku Streaming Stick or other
portable device; HDMI-capable
device
MHL (AVR 1710S/AVR 171S/
AVR 1610S/AVR 161S)
HDMI 1/MHL Analog 1 or 2 HDMI 1/MHL
DVD Audio/Video, SACD,
Blu-ray Disc, HD-DVD player
Disc HDMI 2 Analog 1 or 2 HDMI 2
Cable TV, satellite TV, HDTV
or other device that delivers
television programs
Cable/Sat HDMI 3 Analog 1 or 2 HDMI 3
DVR or set-top box STB HDMI 4 Analog 1 or 2 HDMI 4
Video-game console Game HDMI 5 Analog 1 or 2 HDMI 5
Any audio or video device,
e.g., CD player, camcorder,
cassette deck
Aux Coaxial or Optical Analog 1 or 2
Composite Video 1 or 2 (not used
for audio-only devices)
Any audio-only playback device
(e.g. CD player, cassette deck)
Audio Coaxial or Optical Analog 1 or 2 None
iPod, iPhone, iPad or USB
memory stick
USB/iPod USB N/A N/A
Appendix
