Table A2 – Speaker/Channel Setting Defaults
Default Settings
Your Settings
Position 1
Your Settings
Position 2
Front Left/Right SpeakersON
Center Speaker ON
Surround Left/Right SpeakersON
Surround Back Left/Right Speakers
(AVR 1710S/AVR 171S only)
OFF
Subwoofer ON
Front Left/Right Speakers Crossover Frequency 100Hz
Center Speaker Crossover Frequency 100Hz
Surround Left/Right Speakers Crossover Frequency 100Hz
Surround Back Left/Right or Left/Right Front Height Speakers
Crossover Frequency (AVR 1710S/AVR 171S only)
100Hz
Subwoofer Mode (if Front Speakers are set to Large) L/R + LFE
Front Left Level 0dB
Center Level 0dB
Front Right Level 0dB
Surround Right Level 0dB
Surround Back Right/Front Height Right Level
(AVR 1710S/AVR 171S only)
0dB
Surround Back Left/Front Height Left Level
(AVR 1710S/AVR 171S only)
0dB
Surround Left Level 0dB
Subwoofer Level 0dB
Table A3 – Delay Setting Defaults
Speaker Position
Distance From Speaker
to Listening Position
Your Delay Settings
Position 1
Your Delay Settings
Position 2
Front Left 10 feet (3 meters)
Center 10 feet (3 meters)
Front Right 10 feet (3 meters)
Surround Right 10 feet (3 meters)
Surround Left 10 feet (3 meters)
Surround Back Right/Front Height Right 10 feet (3 meters)
Surround Back Left/Front Height Left 10 feet (3 meters)
Subwoofer 10 feet (3 meters)
39
ENGLISH
AVR
Appendix
Table A4 – Source Settings
Cable/
Sat
Disc MHL Radio TV iPod/ USB
Network /
vTuner
Game AUX STB Audio Bluetooth
Connected Device USB N/A
Surround Mode
Video Input N/A N/A N/AN/A N/A
Audio Input Radio HDMI ARCUSB Network Bluetooth
Night Mode N/AN/A N/A N/A
Adjust Lip Sync N/AN/A N/A N/A
Change Name N/AN/A N/A N/A N/A
Zone 2 Input N/AN/A N/AN/A
Bass
Treble
Table A5 – HARMAN NSP Settings
Default Settings Your Settings
Stage Width 45
Stage Depth 30
Table A6 – Dolby Pro Logic II Music Settings
Default Settings Your Settings
Center Width 3
Dimension 0
Panorama Off
