CONTROL UNIT
103
11
4
Once the coil has been desoldered, unscrew and
remove the (4) Hex Nut which secure the Coil
Assy to the Controller.
5
The Coil Assy may be broken down further into
individual components, but for the purpose of
this exercise only the assembly is removed.
FIG. 11-5d
HEX NUT (4)
FIG. 11-5c
