The LCD display screen is adjusted prior to leaving the factory. Avoid any
unnecessary adjustment.
● If the adjustment method in this manual does not resolve the problem, contact
the customer service number in this manual or your supplier.
● Do not stick tape, stickers or anything else onto the screen. Any kind of
adhesive may damage the surface of the screen.
10-1 GENERAL DESCRIPTION
This specication applies to the 54.6 inch Color TFT-LCD Module P550HVN02.0. This LCD module
has a TFT active matrix type liquid crystal panel 1,920x1,080 pixels, and diagonal size of 54.6 inch.
This module supports 1920x1080 mode. Each pixel is divided into Red, Green and Blue sub-pixels
or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is
determined with a 10-bit gray scale signal for each dot.
The P550HVN02.0 has been designed to apply the 10-bit 2 channel LVDS interface method. It is
intended to support displays which have high brightness, wide viewing angle, high color saturation, and
high color depth.
* General Information
Items Specication Unit Note
Active Screen Size 54.6 Inch
Display Area 1209.6(H) x 680.4(V) mm
Outline Dimension 1235.6(H) x 706.4(V) x 25.5(D) mm 1
Driver Element a-Si TFT active matrix
Display Colors 10 bit (8bit+FRC), 1073.7M Colors
Number of Pixels 1,920x1080 Pixel
Pixel Pitch 0.21 (H) x 0.63(W) mm
Pixel Arrangement RGB vertical stripe
Display Operation Mode Normally Black
Display Orientation Landscape/Portrait Enable
Surface Treatment AG Haze = 11%
