12
PART DESCRIPTIONS
4
- In this product, the Cabinet which houses the LCD display screen shall be refered to as the Monitor Cabinet
- Facing the LCD display screen, the left side is the 1P seat and the right side is the 2P seat.
FIG. 4 Name of Each Part
4
PARTS DESCRIPTION
CASH SECURITY DOOR
MONITOR CABINET
BILLBOARD
1P SIDE CONTROL UNIT
LEFT SEAT SIDE
2P SIDE CONTROL UNIT
RIGHT SEAT SIDE
1P SIDE START BUTTON
LEFT SEAT SIDE
2P SIDE START BUTTON
RIGHT SEAT SIDE
REAR CABINET
GUN CABINET
AC UNIT
LCD DISPLAY
LEVER
