Hasbro Sega Transformers Shadows Rising User Manual

REPLACING LAMPS AND LIGHTING
111
13
1
Turn o the power.
2
Unlock and open the Cabinet coin door.
13-2 START BUTTON LAMP
FIG. 13-2a
3
Remove Lamp and Switch housing from the Button
by pulling the housing away from the button. These
can sometimes be a little tight upon on initial removal.
4
The bulb is a simple “push t” type. Simply hold onto the bulb and pull directly out of the socket. DO NOT
twist the bulb as this will cause the bulb to shatter which inturn may result in an injury
FIG. 13-2b
FIG. 13-2c
Lamp Housing
