ASSEMBLY AND INSTALLATION
6
6-6 SECURING THE GUN CABINET
2
Secure the (4) M8 xings of the JOINT GUN CABI REDUCED
FIG. 6-6b
1
Remove the Game BD access door to gain access to the internal xings of the JOINT GUN CABI
REDUCED. Have another person oer the JOINT GUN CABI REDUCED in place and secure all (4) M8
xings.
FIG. 6-6a
M8 FIXINGS
5
Secure the top of the SIDE SASH L using the (1) M4 xing as shown. Complete the same process for the
SIDE SASH on the right hand side.
